DSA 1: Big-O - Arrays and Sets

1. Arrays

1.1 Array Operation - Summary

• Read \((1)\)

• Search \((n)\)

• Insert \((n+1)\)

• Delete \((n)\)

1.2 Array Operation - Details

1.2.1 Read \((1)\):

• \(1\) (worse)
• \(1\) (best)

1.2.2 Search \((n)\):

• \(n\) (worse: target is last value found)

• \(1\) (best: target is first value found)

1.2.3 Delete \((n)\):

1.2.3a Delete \((n)\) - Worse:

{\(n\)}=({\(1\)} \(+\) {\(n-1\)}): worse - delete \(first\) item or \(arr[0]\):

• {\(1\)}: delete item at \(arr[0]\)

• {\(n-1\)}: shift whole array, left one item at a time:

  • \(arr[1] \to arr[0]\) (\(index\_1 \to index\_0\))
  • \(arr[2] \to arr[1]\) (\(index\_2 \to index\_1\))
  • \(...\)
  • \(arr[n] \to arr[n-1]\) (\(inde`x\_[n] \to index\_[n-1]\))

1.2.3b Delete \((1)\) - Best

{\(1\)}: best - delete \(last\) item or \(arr[-1]\)

1.2.4 Insert \((n+1)\)

1.2.4a Insert \((n+1)\) - Worse:

{\(n + 1\)}: worse - insert at \(front\) or \(arr[0]\):

• {\(n\)}: whole existing array of length {\(n\)} needs to move right by {\(1\)}:

  • starts at {\(n\)}, moves it right to {\(n+1\)}
  • then {\(n-1\)} moves to {\(n\)}… {\(n\_times\)} or {\(n\_steps\)}

  • index \([0]\) becomes empty

  • index \([0]\) retains same memory address (might change for diff languages)

• {\(1\)}: insert the finally vacant spot at index 0, same memory address

1.2.4b Insert \((1)\) - Best:

{\(1\)}: best - insert at \(end\) or \(arr[-1]\):

Computers may have to allocate additional memory cells toward this array (language specific)

2. Array-Based Sets

A data stucture that does not allow duplicates values within it.

Useful: data without duplicates (e.g.online phonebook)

2.1 Classic Arrays vs Array-Based Sets - Differences

An array-based set:

• is an array
• with one additional constraint
• of barring duplicates

2.2 Classic Arrays vs Array-Based Sets - Operations Comparison Table

Operation	Array	Array-Based Set	Difference	Change
Read	\(O(1,1)\)	\(O(1,1)\)	Same	None
Search	\(O(1,n)\)	\(O(1,n)\)	Same	None
Delete	\(O(1,n)\)	\(O(1,n)\)	Same	None
Insert	\(O(1,n+1)\)	\(O(n+1,n*n+1)\) or \(O(n+1,2n+1)\)	\(O(worse,worse)\)	\(O_{best}(1 \to n+1)\) and \(O_{worse}(n+1 \to 2n+1)\)

2.3 Array-Based Set Operation - Detailed

2.3.1 Read \((1)\), Search \((n)\), Delete \((n)\)

• Read \((1,1)\)

• Search \((1,n)\)

• Delete \((1,n)\)

• Insert \((n+1,2n+1)\)

2.3.2 Insert \((2n+1)\): Different to Classic Arrays

2.3.2a Insert \((2n+1)\) - Worse

{\(n*n+1\)} - worse, insert at the \(front\):

• {\(n\)}: search whole array {\(n\_times\)}


• {\(n\)}: shift whole array, right (one-item-at-a-time) i.e. {\(n\_times\)}:

  • \(arr[n] \to arr[n+1]\) (\(index\_[n] \to index\_[n+1]\))

  • \(arr[n-1] \to arr[n]\) (\(index\_[n-1] \to index\_[n]\))

  • \(...\)

  • \(arr[0] \to arr[1]\) (\(index\_[0] \to index\_[1]\))

• {\(1\)}: insert at index 0, same memory address

2.3.2b Insert \((n+1)\) - Best

{\(n+1\)} - best, insert at the \(end\):

• Search array (for dupes) + insert (at end)

2.3.2c Insert \((m*n+1)\) - Medium

{\(m*n+1\)} - medium, insert at the \(arr[j]\) or \(index\_[j]\)):

• {\(n\)}: search whole array {\(n\_times\)}

• {\(m\)}: shift whole array {\(n\_times\)} where {\(m\)} \(=\) {\(n-j\)}:

  • if want to insert at \(index\_[j]\): all items after \(index\_[j]\) by one
  • thus we shift right {\(m\)} \(=\) {\(n-j\)} items
  • \(arr[n] \to arr[n+1]\) (\(index\_[n] \to index\_[n+1]\))
  • \(...\)
  • \(arr[j] \to arr[j+1]\) (\(index\_[j] \to index\_[j+1]\))
  • or
  • \(arr[n-m] \to arr[n-m+1]\) (\(index\_[n-m] \to index\_[n-m+1]\))

• {\(1\)}: insert at \(arr[j]\) or \(arr[n-m]\)

2.3.3 Inserting at \(arr[j]\) hand-drawn
